    • 首页欧美晶振SKYWORKS晶振思佳讯有源晶振,571ACA000148DG,6G光纤通道晶振

    思佳讯有源晶振,571ACA000148DG,6G光纤通道晶振

    • 频率：24.576MHz
    • 尺寸：7.0×5.0mm
    • 应　用： 欧美进口晶振,思佳讯有源晶振,Si571压控晶振,571ACA000148DG晶振,VCXO晶振,7050mm晶振,SMD晶体,石英晶体振荡器,LVPECL晶振,差分晶振,频率24.576MHz,电压3.3V,工作温度-40~85°C,无铅环保晶振,低抖动晶振,高品质晶振,6...
    • RoHS RoHS2

    思佳讯有源晶振,    571ACA000148DG,6G光纤通道晶振,欧美进口晶振,思佳讯有源晶振,Si571压控晶振,571ACA000148DG晶振,VCXO晶振,7050mm晶振,SMD晶体,石英晶体振荡器,LVPECL晶振,差分晶振,频率24.576MHz,电压3.3V,工作温度-40~85°C,无铅环保晶振,低抖动晶振,高品质晶振,6G光纤通道晶振,网络交换晶振,无线通信晶振,时钟和数据恢复晶振.
    思佳讯有源晶振,571ACA000148DG,6G光纤通道晶振特点：
    •可与任意速率输出频率从10MHz到945MHz和选择频率到1.4 GHz

    •I2C串行接口

    •第三代DSPLL®具有优越的抖动性能

    •频率稳定性优于SAW-based振荡器

    •内部固定晶频，可靠性高，老化低

    •具备CMOS, LVPECL，LVDS和CML输出

    •3.3, 2.5和1.8 V电源选项

    •工业标准的5 × 7mm封装和引脚

    •无铅，符合RoHS标准


    思佳讯有源晶振,571ACA000148DG,6G光纤通道晶振规格表
    项目 符号 规格说明 条件
    额定频率 f_nom 24.576MHz 请联系我们以便获取其它可用频率的相关信息
    电源电压 Vcc 3.3V
    储存温度 T_stg -55℃~+125℃ 裸存
    工作温度 T_use -40℃~ +85℃
    频率稳定性 f_tol ±50 ppm +25℃,超出标准的规格说明请联系我们
    电源电流 IDD 130mA Max
    LVPECL
    对称性（占空比） SYM 45%~55% 在输出交叉点
    输出电压 VOD 1.9VPP Max
    LVPECL
    VO 1.25V Max
    输入电压 VIH 0.75XVDD Min

    VIL 0.5V Max
    上升下降时间 tr/tf 350ps Max
    LVPECL
    起始时间 t str 10ms Max
    相位抖动 tpj 0.62ps Max
    Differential Formats

    思佳讯有源晶振,571ACA000148DG,6G光纤通道晶振尺寸图


    原厂编码 品牌 型号 频率 输出 电压 频率稳定性
    571AEA000122DG Skyworks Solutions Inc. Si571 1 GHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AEA000122DGR Skyworks Solutions Inc. Si571 1 GHz LVPECL 2.97V ~ 3.63V ±20ppm
    571BMC000804DG Skyworks Solutions Inc. Si571 156.25 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BMC000804DGR Skyworks Solutions Inc. Si571 156.25 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BAA000522DG Skyworks Solutions Inc. Si571 545 MHz LVDS 2.97V ~ 3.63V ±100ppm
    571BBA000107DG Skyworks Solutions Inc. Si571 10 MHz LVDS 2.97V ~ 3.63V ±100ppm
    571BBA000126DG Skyworks Solutions Inc. Si571 200 MHz LVDS 2.97V ~ 3.63V ±100ppm
    571BFA000166DG Skyworks Solutions Inc. Si571 622.08 MHz LVDS 2.97V ~ 3.63V ±50ppm
    571ECA000107DG Skyworks Solutions Inc. Si571 10 MHz LVPECL 2.25V ~ 2.75V ±50ppm
    571FCA000122DG Skyworks Solutions Inc. Si571 1 GHz LVDS 2.25V ~ 2.75V ±50ppm
    571FCA000313DG Skyworks Solutions Inc. Si571 300 MHz LVDS 2.25V ~ 2.75V ±50ppm
    571FCA001742DG Skyworks Solutions Inc. Si571 300 MHz LVDS 2.25V ~ 2.75V ±50ppm
    571FDA000113DG Skyworks Solutions Inc. Si571 311.04 MHz LVDS 2.25V ~ 2.75V ±50ppm
    571MDA001661DG Skyworks Solutions Inc. Si571 496.685652 MHz LVPECL 2.97V ~ 3.63V ±50ppm
    571NCA000107DG Skyworks Solutions Inc. Si571 10 MHz LVDS 2.97V ~ 3.63V ±50ppm
    571SCA000121DG Skyworks Solutions Inc. Si571 100 MHz LVDS 2.25V ~ 2.75V ±50ppm
    571ACA000107DG Skyworks Solutions Inc. Si571 10 MHz LVPECL 2.97V ~ 3.63V ±50ppm
    571ACA000112DG Skyworks Solutions Inc. Si571 10 MHz LVPECL 2.97V ~ 3.63V ±50ppm
    571ACA000122DG Skyworks Solutions Inc. Si571 1 GHz LVPECL 2.97V ~ 3.63V ±50ppm
    571ACA000141DG Skyworks Solutions Inc. Si571 56.32 MHz LVPECL 2.97V ~ 3.63V ±50ppm
    571ACA000148DG Skyworks Solutions Inc. Si571 24.576 MHz LVPECL 2.97V ~ 3.63V ±50ppm
    571ACA000206DG Skyworks Solutions Inc. Si571 321.4 MHz LVPECL 2.97V ~ 3.63V ±50ppm
    571ACA000209DG Skyworks Solutions Inc. Si571 14.1 MHz LVPECL 2.97V ~ 3.63V ±50ppm
    571ADA000107DG Skyworks Solutions Inc. Si571 10 MHz LVPECL 2.97V ~ 3.63V ±50ppm
    571ADA000112DG Skyworks Solutions Inc. Si571 10 MHz LVPECL 2.97V ~ 3.63V ±50ppm
    571ADA000382DG Skyworks Solutions Inc. Si571 1.375 GHz LVPECL 2.97V ~ 3.63V ±50ppm
    571ADA001549DG Skyworks Solutions Inc. Si571 993.409691 MHz LVPECL 2.97V ~ 3.63V ±50ppm
    571ADA001841DG Skyworks Solutions Inc. Si571 802.5 MHz LVPECL 2.97V ~ 3.63V ±50ppm
    571AFA000122DG Skyworks Solutions Inc. Si571 1 GHz LVPECL 2.97V ~ 3.63V ±50ppm
    571AFA000133DG Skyworks Solutions Inc. Si571 500 MHz LVPECL 2.97V ~ 3.63V ±50ppm
    571BCA000107DG Skyworks Solutions Inc. Si571 10 MHz LVDS 2.97V ~ 3.63V ±50ppm
    571BCA000112DG Skyworks Solutions Inc. Si571 10 MHz LVDS 2.97V ~ 3.63V ±50ppm
    571BCA000121DG Skyworks Solutions Inc. Si571 100 MHz LVDS 2.97V ~ 3.63V ±50ppm
    571BCA000395DG Skyworks Solutions Inc. Si571 904.64 MHz LVDS 2.97V ~ 3.63V ±50ppm
    571BCA000675DG Skyworks Solutions Inc. Si571 51.84 MHz LVDS 2.97V ~ 3.63V ±50ppm
    571BDA000107DG Skyworks Solutions Inc. Si571 10 MHz LVDS 2.97V ~ 3.63V ±50ppm
    571BDA001064DG Skyworks Solutions Inc. Si571 589.824 MHz LVDS 2.97V ~ 3.63V ±50ppm
    571BDA001122DG Skyworks Solutions Inc. Si571 1.4 GHz LVDS 2.97V ~ 3.63V ±50ppm
    571BDA001628DG Skyworks Solutions Inc. Si571 156.25 MHz LVDS 2.97V ~ 3.63V ±50ppm
    571BDA001721DG Skyworks Solutions Inc. Si571 830 MHz LVDS 2.97V ~ 3.63V ±50ppm
    571ADA000164DG Skyworks Solutions Inc. Si571 400 MHz LVPECL 3.3V ±50ppm
    571ADA000233DG Skyworks Solutions Inc. Si571 10 MHz LVPECL 3.3V ±50ppm
    571ADA001971DG Skyworks Solutions Inc. Si571 873.51542 MHz LVPECL 3.3V ±50ppm
    571ECA000112DG Skyworks Solutions Inc. Si571 10 MHz LVPECL 2.5V ±50ppm
    571ECA000399DG Skyworks Solutions Inc. Si571 10 MHz LVPECL 2.5V ±50ppm
    571ECA002033DG Skyworks Solutions Inc. Si571 10 MHz LVPECL 2.5V ±50ppm
    571FFA000161DG Skyworks Solutions Inc. Si571 491.52 MHz LVDS 2.5V ±50ppm
    571ADA000106DG Skyworks Solutions Inc. Si571 155.52 MHz LVPECL 3.3V ±50ppm
    571ACA000106DG Skyworks Solutions Inc. Si571 155.52 MHz LVPECL 3.3V ±50ppm
    571ADA002143DG Skyworks Solutions Inc. Si571 444 MHz LVPECL 3.3V ±50ppm
    571BDA000115DG Skyworks Solutions Inc. Si571 125 MHz LVDS 3.3V ±50ppm
    571BDA000112DG Skyworks Solutions Inc. Si571 10 MHz LVDS 3.3V ±50ppm
    571ADA000991DG Skyworks Solutions Inc. Si571 135 MHz LVPECL 3.3V ±50ppm
    571ADA000115DG Skyworks Solutions Inc. Si571 125 MHz LVPECL 3.3V ±50ppm
    571BDA000436DG Skyworks Solutions Inc. Si571 10 MHz LVDS 3.3V ±50ppm
    571BGA000107DGR Skyworks Solutions Inc. Si571 10 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BGA000112DGR Skyworks Solutions Inc. Si571 10 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BGA000121DGR Skyworks Solutions Inc. Si571 100 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BGA000122DGR Skyworks Solutions Inc. Si571 1 GHz LVDS 2.97V ~ 3.63V ±20ppm
    571BGA001666DGR Skyworks Solutions Inc. Si571 125 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BHA000107DGR Skyworks Solutions Inc. Si571 10 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BHA000170DGR Skyworks Solutions Inc. Si571 915 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BHA000278DGR Skyworks Solutions Inc. Si571 146.52 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BJA000107DGR Skyworks Solutions Inc. Si571 10 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BJA000112DGR Skyworks Solutions Inc. Si571 10 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BJA000118DGR Skyworks Solutions Inc. Si571 156.25 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BJA000372DGR Skyworks Solutions Inc. Si571 800 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BJA001082DGR Skyworks Solutions Inc. Si571 320 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BJA001118DGR Skyworks Solutions Inc. Si571 784.247202 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BJA001898DGR Skyworks Solutions Inc. Si571 102.4 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BMA000107DGR Skyworks Solutions Inc. Si571 10 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BMA000112DGR Skyworks Solutions Inc. Si571 10 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BMA000118DGR Skyworks Solutions Inc. Si571 156.25 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BMA000121DGR Skyworks Solutions Inc. Si571 100 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BMA000122DGR Skyworks Solutions Inc. Si571 1 GHz LVDS 2.97V ~ 3.63V ±20ppm
    571BMA000164DGR Skyworks Solutions Inc. Si571 400 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BMA000179DGR Skyworks Solutions Inc. Si571 312.5 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BMA000788DGR Skyworks Solutions Inc. Si571 438 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BMA000804DGR Skyworks Solutions Inc. Si571 156.25 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571EJA000763DGR Skyworks Solutions Inc. Si571 1.09 GHz LVPECL 2.25V ~ 2.75V ±20ppm
    571FGA000126DGR Skyworks Solutions Inc. Si571 200 MHz LVDS 2.25V ~ 2.75V ±20ppm
    571FHA000103DGR Skyworks Solutions Inc. Si571 155.52 MHz LVDS 2.25V ~ 2.75V ±20ppm
    571FJA000107DGR Skyworks Solutions Inc. Si571 10 MHz LVDS 2.25V ~ 2.75V ±20ppm
    571FJA000466DGR Skyworks Solutions Inc. Si571 161.733417 MHz LVDS 2.25V ~ 2.75V ±20ppm
    571FJA000741DGR Skyworks Solutions Inc. Si571 156.25 MHz LVDS 2.25V ~ 2.75V ±20ppm
    571FJA000742DGR Skyworks Solutions Inc. Si571 156.25 MHz LVDS 2.25V ~ 2.75V ±20ppm
    571FJA000743DGR Skyworks Solutions Inc. Si571 156.25 MHz LVDS 2.25V ~ 2.75V ±20ppm
    571FJA000744DGR Skyworks Solutions Inc. Si571 156.25 MHz LVDS 2.25V ~ 2.75V ±20ppm
    571FJA000745DGR Skyworks Solutions Inc. Si571 156.25 MHz LVDS 2.25V ~ 2.75V ±20ppm
    571FMA000107DGR Skyworks Solutions Inc. Si571 10 MHz LVDS 2.25V ~ 2.75V ±20ppm
    571MHA000107DGR Skyworks Solutions Inc. Si571 10 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571MJA000121DGR Skyworks Solutions Inc. Si571 100 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571MJA000542DGR Skyworks Solutions Inc. Si571 698.812335 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571MMA000107DGR Skyworks Solutions Inc. Si571 10 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571MMA000122DGR Skyworks Solutions Inc. Si571 1 GHz LVPECL 2.97V ~ 3.63V ±20ppm
    571NEA001677DGR Skyworks Solutions Inc. Si571 873.515 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571NHA000399DGR Skyworks Solutions Inc. Si571 10 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571NJA000112DGR Skyworks Solutions Inc. Si571 10 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571NJA000143DGR Skyworks Solutions Inc. Si571 117 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571NMA000107DGR Skyworks Solutions Inc. Si571 10 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571NMA000409DGR Skyworks Solutions Inc. Si571 10 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571SHA000115DGR Skyworks Solutions Inc. Si571 125 MHz LVDS 2.25V ~ 2.75V ±20ppm
    571SHA001843DGR Skyworks Solutions Inc. Si571 1.29948467 GHz LVDS 2.25V ~ 2.75V ±20ppm
    571AEA000107DGR Skyworks Solutions Inc. Si571 10 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AEA000112DGR Skyworks Solutions Inc. Si571 10 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AEA000121DGR Skyworks Solutions Inc. Si571 100 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AEA000133DGR Skyworks Solutions Inc. Si571 500 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AEA000197DGR Skyworks Solutions Inc. Si571 614.4 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AEA000227DGR Skyworks Solutions Inc. Si571 980 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AEA000444DGR Skyworks Solutions Inc. Si571 1 GHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AEA000462DGR Skyworks Solutions Inc. Si571 1 GHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AEA000467DGR Skyworks Solutions Inc. Si571 990 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AEA000498DGR Skyworks Solutions Inc. Si571 825 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AEA000928DGR Skyworks Solutions Inc. Si571 1 GHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AEA001455DGR Skyworks Solutions Inc. Si571 100 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AEA001677DGR Skyworks Solutions Inc. Si571 873.515 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AEA001678DGR Skyworks Solutions Inc. Si571 993.41 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AEA001679DGR Skyworks Solutions Inc. Si571 873.515 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AEA001680DGR Skyworks Solutions Inc. Si571 993.41 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AEA001796DGR Skyworks Solutions Inc. Si571 873.51542 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AGA000107DGR Skyworks Solutions Inc. Si571 10 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AGA000112DGR Skyworks Solutions Inc. Si571 10 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AGA000192DGR Skyworks Solutions Inc. Si571 647.239 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AGA000239DGR Skyworks Solutions Inc. Si571 233.639 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AGA000240DGR Skyworks Solutions Inc. Si571 877.969 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AGA000420DGR Skyworks Solutions Inc. Si571 644.53125 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AHA000106DGR Skyworks Solutions Inc. Si571 155.52 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AHA000107DGR Skyworks Solutions Inc. Si571 10 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AHA000112DGR Skyworks Solutions Inc. Si571 10 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AHA000122DGR Skyworks Solutions Inc. Si571 1 GHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AHA000372DGR Skyworks Solutions Inc. Si571 800 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AHA000550DGR Skyworks Solutions Inc. Si571 146.54 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AHA000618DGR Skyworks Solutions Inc. Si571 437.5 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AHA001612DGR Skyworks Solutions Inc. Si571 698.812334 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AJA000112DGR Skyworks Solutions Inc. Si571 10 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AJA000121DGR Skyworks Solutions Inc. Si571 100 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AJA000137DGR Skyworks Solutions Inc. Si571 1.024 GHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AJA000192DGR Skyworks Solutions Inc. Si571 647.239 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AJA000374DGR Skyworks Solutions Inc. Si571 200 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AJA000400DGR Skyworks Solutions Inc. Si571 10 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AJA000409DGR Skyworks Solutions Inc. Si571 10 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AJA000512DGR Skyworks Solutions Inc. Si571 706.25 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AJA001118DGR Skyworks Solutions Inc. Si571 784.247202 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AJA001212DGR Skyworks Solutions Inc. Si571 10 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AJA001741DGR Skyworks Solutions Inc. Si571 70.656 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AJA001748DGR Skyworks Solutions Inc. Si571 10 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AJA001757DGR Skyworks Solutions Inc. Si571 1.024 GHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AJA001788DGR Skyworks Solutions Inc. Si571 993.40969 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AJA001789DGR Skyworks Solutions Inc. Si571 1.0242396 GHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AJA001863DGR Skyworks Solutions Inc. Si571 978 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AJA001959DGR Skyworks Solutions Inc. Si571 873 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AMA000105DGR Skyworks Solutions Inc. Si571 622.08 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AMA000107DGR Skyworks Solutions Inc. Si571 10 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AMA000112DGR Skyworks Solutions Inc. Si571 10 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AMA000165DGR Skyworks Solutions Inc. Si571 622.08 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AMA000166DGR Skyworks Solutions Inc. Si571 622.08 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AMA000444DGR Skyworks Solutions Inc. Si571 1 GHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AMA000501DGR Skyworks Solutions Inc. Si571 1.333 GHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AMA000788DGR Skyworks Solutions Inc. Si571 438 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571BEA000107DGR Skyworks Solutions Inc. Si571 10 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BEA000121DGR Skyworks Solutions Inc. Si571 100 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BEA000122DGR Skyworks Solutions Inc. Si571 1 GHz LVDS 2.97V ~ 3.63V ±20ppm
    571BEA000126DGR Skyworks Solutions Inc. Si571 200 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BEA001828DGR Skyworks Solutions Inc. Si571 1.1 GHz LVDS 2.97V ~ 3.63V ±20ppm
    571AJA001973DGR Skyworks Solutions Inc. Si571 993 MHz LVPECL 3.3V ±20ppm
    571AMA001971DGR Skyworks Solutions Inc. Si571 873.51542 MHz LVPECL 3.3V ±20ppm
    571BGA000476DGR Skyworks Solutions Inc. Si571 322.265625 MHz LVDS 3.3V ±20ppm
    571AMA000121DGR Skyworks Solutions Inc. Si571 100 MHz LVPECL 3.3V ±20ppm
    571BJA000215DGR Skyworks Solutions Inc. Si571 27 MHz LVDS 3.3V ±20ppm
    571AJA000337DGR Skyworks Solutions Inc. Si571 155.52 MHz LVPECL 3.3V ±20ppm
    571NEA001679DGR Skyworks Solutions Inc. Si571 873.515 MHz LVDS 3.3V ±20ppm
    571AEA002238DGR Skyworks Solutions Inc. Si571 63 MHz LVPECL 3.3V ±20ppm
    571NJA000181DGR Skyworks Solutions Inc. Si571 148.5 MHz LVDS 3.3V ±20ppm
    571BEA002345DGR Skyworks Solutions Inc. Si571 873.49794 MHz LVDS 3.3V ±20ppm
    571AJA002230DGR Skyworks Solutions Inc. Si571 155.48 MHz LVPECL 3.3V ±20ppm
    571BGA000107DG Skyworks Solutions Inc. Si571 10 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BGA000112DG Skyworks Solutions Inc. Si571 10 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BGA000121DG Skyworks Solutions Inc. Si571 100 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BGA000122DG Skyworks Solutions Inc. Si571 1 GHz LVDS 2.97V ~ 3.63V ±20ppm
    571BGA001666DG Skyworks Solutions Inc. Si571 125 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BHA000107DG Skyworks Solutions Inc. Si571 10 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BHA000170DG Skyworks Solutions Inc. Si571 915 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BHA000278DG Skyworks Solutions Inc. Si571 146.52 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BJA000107DG Skyworks Solutions Inc. Si571 10 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BJA000112DG Skyworks Solutions Inc. Si571 10 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BJA000118DG Skyworks Solutions Inc. Si571 156.25 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BJA000372DG Skyworks Solutions Inc. Si571 800 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BJA001082DG Skyworks Solutions Inc. Si571 320 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BJA001118DG Skyworks Solutions Inc. Si571 784.247202 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BJA001898DG Skyworks Solutions Inc. Si571 102.4 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BMA000107DG Skyworks Solutions Inc. Si571 10 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BMA000112DG Skyworks Solutions Inc. Si571 10 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BMA000118DG Skyworks Solutions Inc. Si571 156.25 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BMA000121DG Skyworks Solutions Inc. Si571 100 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BMA000122DG Skyworks Solutions Inc. Si571 1 GHz LVDS 2.97V ~ 3.63V ±20ppm
    571BMA000164DG Skyworks Solutions Inc. Si571 400 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BMA000179DG Skyworks Solutions Inc. Si571 312.5 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BMA000788DG Skyworks Solutions Inc. Si571 438 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BMA000804DG Skyworks Solutions Inc. Si571 156.25 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571EJA000763DG Skyworks Solutions Inc. Si571 1.09 GHz LVPECL 2.25V ~ 2.75V ±20ppm
    571FGA000126DG Skyworks Solutions Inc. Si571 200 MHz LVDS 2.25V ~ 2.75V ±20ppm
    571FHA000103DG Skyworks Solutions Inc. Si571 155.52 MHz LVDS 2.25V ~ 2.75V ±20ppm
    571FJA000107DG Skyworks Solutions Inc. Si571 10 MHz LVDS 2.25V ~ 2.75V ±20ppm
    571FJA000466DG Skyworks Solutions Inc. Si571 161.733417 MHz LVDS 2.25V ~ 2.75V ±20ppm
    571FJA000741DG Skyworks Solutions Inc. Si571 156.25 MHz LVDS 2.25V ~ 2.75V ±20ppm
    571FJA000742DG Skyworks Solutions Inc. Si571 156.25 MHz LVDS 2.25V ~ 2.75V ±20ppm
    571FJA000743DG Skyworks Solutions Inc. Si571 156.25 MHz LVDS 2.25V ~ 2.75V ±20ppm
    571FJA000744DG Skyworks Solutions Inc. Si571 156.25 MHz LVDS 2.25V ~ 2.75V ±20ppm
    571FJA000745DG Skyworks Solutions Inc. Si571 156.25 MHz LVDS 2.25V ~ 2.75V ±20ppm
    571FMA000107DG Skyworks Solutions Inc. Si571 10 MHz LVDS 2.25V ~ 2.75V ±20ppm
    571MHA000107DG Skyworks Solutions Inc. Si571 10 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571MJA000121DG Skyworks Solutions Inc. Si571 100 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571MJA000542DG Skyworks Solutions Inc. Si571 698.812335 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571MMA000107DG Skyworks Solutions Inc. Si571 10 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571MMA000122DG Skyworks Solutions Inc. Si571 1 GHz LVPECL 2.97V ~ 3.63V ±20ppm
    571NEA001677DG Skyworks Solutions Inc. Si571 873.515 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571NHA000399DG Skyworks Solutions Inc. Si571 10 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571NJA000112DG Skyworks Solutions Inc. Si571 10 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571NJA000143DG Skyworks Solutions Inc. Si571 117 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571NMA000107DG Skyworks Solutions Inc. Si571 10 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571NMA000409DG Skyworks Solutions Inc. Si571 10 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571SHA000115DG Skyworks Solutions Inc. Si571 125 MHz LVDS 2.25V ~ 2.75V ±20ppm
    571SHA001843DG Skyworks Solutions Inc. Si571 1.29948467 GHz LVDS 2.25V ~ 2.75V ±20ppm
    571AEA000107DG Skyworks Solutions Inc. Si571 10 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AEA000112DG Skyworks Solutions Inc. Si571 10 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AEA000121DG Skyworks Solutions Inc. Si571 100 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AEA000133DG Skyworks Solutions Inc. Si571 500 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AEA000197DG Skyworks Solutions Inc. Si571 614.4 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AEA000227DG Skyworks Solutions Inc. Si571 980 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AEA000444DG Skyworks Solutions Inc. Si571 1 GHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AEA000462DG Skyworks Solutions Inc. Si571 1 GHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AEA000467DG Skyworks Solutions Inc. Si571 990 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AEA000498DG Skyworks Solutions Inc. Si571 825 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AEA000928DG Skyworks Solutions Inc. Si571 1 GHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AEA001455DG Skyworks Solutions Inc. Si571 100 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AEA001677DG Skyworks Solutions Inc. Si571 873.515 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AEA001678DG Skyworks Solutions Inc. Si571 993.41 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AEA001679DG Skyworks Solutions Inc. Si571 873.515 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AEA001680DG Skyworks Solutions Inc. Si571 993.41 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AEA001796DG Skyworks Solutions Inc. Si571 873.51542 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AGA000107DG Skyworks Solutions Inc. Si571 10 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AGA000112DG Skyworks Solutions Inc. Si571 10 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AGA000192DG Skyworks Solutions Inc. Si571 647.239 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AGA000239DG Skyworks Solutions Inc. Si571 233.639 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AGA000240DG Skyworks Solutions Inc. Si571 877.969 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AGA000420DG Skyworks Solutions Inc. Si571 644.53125 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AHA000106DG Skyworks Solutions Inc. Si571 155.52 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AHA000107DG Skyworks Solutions Inc. Si571 10 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AHA000112DG Skyworks Solutions Inc. Si571 10 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AHA000122DG Skyworks Solutions Inc. Si571 1 GHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AHA000372DG Skyworks Solutions Inc. Si571 800 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AHA000550DG Skyworks Solutions Inc. Si571 146.54 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AHA000618DG Skyworks Solutions Inc. Si571 437.5 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AHA001612DG Skyworks Solutions Inc. Si571 698.812334 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AJA000112DG Skyworks Solutions Inc. Si571 10 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AJA000121DG Skyworks Solutions Inc. Si571 100 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AJA000137DG Skyworks Solutions Inc. Si571 1.024 GHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AJA000192DG Skyworks Solutions Inc. Si571 647.239 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AJA000374DG Skyworks Solutions Inc. Si571 200 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AJA000400DG Skyworks Solutions Inc. Si571 10 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AJA000409DG Skyworks Solutions Inc. Si571 10 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AJA000512DG Skyworks Solutions Inc. Si571 706.25 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AJA001118DG Skyworks Solutions Inc. Si571 784.247202 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AJA001212DG Skyworks Solutions Inc. Si571 10 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AJA001741DG Skyworks Solutions Inc. Si571 70.656 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AJA001748DG Skyworks Solutions Inc. Si571 10 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AJA001757DG Skyworks Solutions Inc. Si571 1.024 GHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AJA001788DG Skyworks Solutions Inc. Si571 993.40969 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AJA001789DG Skyworks Solutions Inc. Si571 1.0242396 GHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AJA001863DG Skyworks Solutions Inc. Si571 978 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AJA001959DG Skyworks Solutions Inc. Si571 873 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AMA000105DG Skyworks Solutions Inc. Si571 622.08 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AMA000107DG Skyworks Solutions Inc. Si571 10 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AMA000112DG Skyworks Solutions Inc. Si571 10 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AMA000165DG Skyworks Solutions Inc. Si571 622.08 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AMA000166DG Skyworks Solutions Inc. Si571 622.08 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AMA000444DG Skyworks Solutions Inc. Si571 1 GHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AMA000501DG Skyworks Solutions Inc. Si571 1.333 GHz LVPECL 2.97V ~ 3.63V ±20ppm
    571AMA000788DG Skyworks Solutions Inc. Si571 438 MHz LVPECL 2.97V ~ 3.63V ±20ppm
    571BEA000107DG Skyworks Solutions Inc. Si571 10 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BEA000121DG Skyworks Solutions Inc. Si571 100 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BEA000122DG Skyworks Solutions Inc. Si571 1 GHz LVDS 2.97V ~ 3.63V ±20ppm
    571BEA000126DG Skyworks Solutions Inc. Si571 200 MHz LVDS 2.97V ~ 3.63V ±20ppm
    571BEA001828DG Skyworks Solutions Inc. Si571 1.1 GHz LVDS 2.97V ~ 3.63V ±20ppm
    571AJA001973DG Skyworks Solutions Inc. Si571 993 MHz LVPECL 3.3V ±20ppm
    571AMA001971DG Skyworks Solutions Inc. Si571 873.51542 MHz LVPECL 3.3V ±20ppm
    571BGA000476DG Skyworks Solutions Inc. Si571 322.265625 MHz LVDS 3.3V ±20ppm
    571AJA000337DG Skyworks Solutions Inc. Si571 155.52 MHz LVPECL 3.3V ±20ppm
    571BEA002345DG Skyworks Solutions Inc. Si571 873.49794 MHz LVDS 3.3V ±20ppm
    571BJA000215DG Skyworks Solutions Inc. Si571 27 MHz LVDS 3.3V ±20ppm
    571NJA000181DG Skyworks Solutions Inc. Si571 148.5 MHz LVDS 3.3V ±20ppm
    571NEA001679DG Skyworks Solutions Inc. Si571 873.515 MHz LVDS 3.3V ±20ppm
    571AMA000121DG Skyworks Solutions Inc. Si571 100 MHz LVPECL 3.3V ±20ppm
    571AEA002238DG Skyworks Solutions Inc. Si571 63 MHz LVPECL 3.3V ±20ppm
    571AJA002230DG Skyworks Solutions Inc. Si571 155.48 MHz LVPECL 3.3V ±20ppm
    571EJB000111DG Skyworks Solutions Inc. Si571 25 MHz LVPECL 2.25V ~ 2.75V ±20ppm
    571BFA000112DGR Skyworks Solutions Inc. Si571 10 MHz LVDS 2.97V ~ 3.63V ±50ppm
    571MDA000265DGR Skyworks Solutions Inc. Si571 1.3 GHz LVPECL 2.97V ~ 3.63V ±50ppm
    571ADA000133DGR Skyworks Solutions Inc. Si571 500 MHz LVPECL 2.97V ~ 3.63V ±50ppm
    571ADA000803DGR Skyworks Solutions Inc. Si571 148.351648 MHz LVPECL 2.97V ~ 3.63V ±50ppm
    571ADA001211DGR Skyworks Solutions Inc. Si571 700 MHz LVPECL 2.97V ~ 3.63V ±50ppm
    571ADA001243DGR Skyworks Solutions Inc. Si571 900 MHz LVPECL 2.97V ~ 3.63V ±50ppm
    571ADA001548DGR Skyworks Solutions Inc. Si571 993.409692 MHz LVPECL 2.97V ~ 3.63V ±50ppm
    571AFA000112DGR Skyworks Solutions Inc. Si571 10 MHz LVPECL 2.97V ~ 3.63V ±50ppm
    571BDA000282DGR Skyworks Solutions Inc. Si571 10 MHz LVDS 2.97V ~ 3.63V ±50ppm
    571BDA000399DGR Skyworks Solutions Inc. Si571 10 MHz LVDS 2.97V ~ 3.63V ±50ppm
    571BDA000400DGR Skyworks Solutions Inc. Si571 10 MHz LVDS 2.97V ~ 3.63V ±50ppm
    571BDA001517DGR Skyworks Solutions Inc. Si571 433.5 MHz LVDS 2.97V ~ 3.63V ±50ppm
    571BDA001606DGR Skyworks Solutions Inc. Si571 77.76 MHz LVDS 2.97V ~ 3.63V ±50ppm
    571BDA001752DGR Skyworks Solutions Inc. Si571 142.8 MHz LVDS 2.97V ~ 3.63V ±50ppm
    571BFA000112DG Skyworks Solutions Inc. Si571 10 MHz LVDS 2.97V ~ 3.63V ±50ppm
    571MDA000265DG Skyworks Solutions Inc. Si571 1.3 GHz LVPECL 2.97V ~ 3.63V ±50ppm
    571ADA000133DG Skyworks Solutions Inc. Si571 500 MHz LVPECL 2.97V ~ 3.63V ±50ppm
    571ADA000803DG Skyworks Solutions Inc. Si571 148.351648 MHz LVPECL 2.97V ~ 3.63V ±50ppm
    公司：深圳市亿金电子有限公司
    SHENZHEN YIJIN ELECTRONICS CO;LTD
    电话：0755-27876565
    手机：18924600166
    QQ：857950243
    邮箱：yijindz@163.com
    网站：http://www.yijindz.com
    地址：广东省深圳市宝安区新安107国道旁

    相关产品

    首 页|国产晶振|进口晶振|欧美晶振|有源晶振|亿金路程|人才招聘|常见问题|客户留言|网站地图|在线问答|RSS订阅|联系亿金
    Copyright © 1996-2012 亿金电子 版权所有
    电话：+86-0755-27876565 手机:18924600166　MSN:yijindz@msn.cn
    E-mail：yijindz@163.com QQ:857950243
    网站:www.yijindz.com
    地址：深圳市宝安区新安107国道旁甲岸路
    粤ICP备17105583号-2
    诚征下列地区 晶振 | 石英晶振 | 圆柱晶振 | 贴片晶振 | 陶瓷晶振 | 石英晶体谐振器 | 频率元件 的合作伙伴：
    深圳市 广州市 北京 上海 东莞 佛山 中山 顺德 珠海 杭州 温州 武汉 长沙 南京 大连 长春 西安 郑州 澳门 沈阳 南宁 昆明 济南 重庆 成都
    石英晶振,贴片晶振,32.768K晶振,SC-32S精工晶振,SSP-T7精工晶振,SC-20S精工晶振,DST310SKDS晶振,MC-146爱普生晶振,FC-135爱普生晶振,2X6KDS晶振,差分晶振,2520温补晶振,有源贴片晶振,压控晶体振荡器,315M声表面滤波器,F11-315声表面滤波器,CSTCR-G15村田陶瓷晶振,CSTCR-G15村田陶瓷晶振,110K微孔雾化片,16mm陶瓷雾化片,1.7M雾化片,加湿器雾化片,进口晶振,陶瓷晶振,
    kf
    kf
    close
    kf 亿金微信号
